Netberg Demos R210 M4 is a universal single-socket 2U server equipped with the latest AMD EPYC processors.

The innovative, record-setting AMD EPYC design, with up to 32 high-performance “Zen” cores and an unparalleled feature set, delivers greater performance than the competition across a full range of integer, floating point, memory bandwidth, and I/O benchmarks and workloads.

Netberg Demos R210 M4 delivers up to 32 processor cores (64 threads) along with 2TB of DDR4-2666 RAM. 128 PCIe Gen 3 lanes are distributed among six expansion slots, 8 NVMe SSD FP drives, and two M.2 NVMe internal drives.

Performance

• Up to 32 AMD EPYC cores and 16 DIMM slots supporting up to 2TB of DDR4-2666 RAM in a single Netberg Demos R210 M4 system.
• Even a single socket AMD EPYC system offers 128 PCIe Gen 3 lanes to expand its communications and compute power.

Storage

• 12/24 hot-pluggable drives in 2U chassis for a maximum storage density and optimal storage performance.

  Up to 8 NVMe SSD supported.
• Two internal M.2 NVMe drives for the OS deployment.

Expansion

• Six PCIe Gen 3 x8 slots are open for future expansion.

Managebility

• Netberg Demos R210 M4 servers are equipped with service processors for a total system control via a standard web browser via a complete HTML5 engine. An intuitive GUI allows deployment, configuring, monitoring, diagnostics, updating, and server management.
• KVM over IP and Virtual Media technologies help system administrators significantly reduce labor costs related to a server control, decrease the number of CD/DVD media with software and install OS on many servers simultaneously through the platform’s secure hardware tools.
• A new Aspeed 2500 service processor supports SD card storage for useful data: OS images, system logs, screenshots, and recorded videos from the console.

Ease of use

• Almost all components are hot-swappable, reducing service time and cost.
